Semaphore Indicator 43 mm Cutout

Semaphore Indicator LED based 43mm manufactured and exported by MIMIC.
Details:- MIMIC semaphore indicator cutout-43mm
Bezel- 53mm round
Voltage- DC 24,48,110,220
Models-
MIMIC-sp-43-24-dc
MIMIC-sp-43-48-dc
MIMIC-sp-43-110-dc
MIMIC-sp-43-220-dc
Applications :- Circuit Breaker Panel MIMIC Diagram

Specifications :-
Rated Insulation Voltage (Ui) : AC, DC 250V.
Rated Operational Voltage (Ui) : DC 24V, 30V, 48V, 110V, 220V.
Voltage Fluctuation Range : ±15%
Rated Operational Current (Ie) : 11 mAmax
Insulation Resistance : 1000MΩ over Impulse Withstand
Voltage : ± 4500V,
3 Times For EachPole (1.2/50µs) Shock Resistance : 490m/s²
Durability : over 10000 Cycles
Degree Of Protection : IP52
Operating Temperature : -20 to 60° C
Storage Temperature : -30 to 75° C
Relative Humidity : 45 to 85 %
Altitude : Max 2000m
Compatiable Copper Conductor : AWG 20 to 14
Mounting Plate Thickness : 1 to 6mm
Confirming to Standard : IEC 60947-5-1, IEC 60947-1
Indication: vertical red , horizontal green
Connection: 1-red,2-green,3-common
