Bicolour LED Indicator Lamp, Panel Indicator Lamp, 24V, 110V, 230V, MIMIC
Bicolour LED Indicator Lamp, Panel Indicator Lamp, 24V, 110V, 230V, MIMIC
100 in stock
Quantity
SKU:1000
Regular price
Rs. 2,715.18
Regular price
Rs. 4,718.82
Sale price
Rs. 2,715.18
Taxes included.
Shipping calculated at checkout.
Couldn't load pickup availability
| Power | 24,30,48,110,220 V DC |
| Wattage | 3 watt |
| Lighting Color | Red and green |
| Lighting Type | LED |
| Body Material | PBT Fire retardent,PBT |
| Brand | MIMIC |
| Country of Origin | Made in India |
Minimum order quantity: 1 Piece
Semaphore Indicator LED based 43mm manufactured and exported by MIMIC.
Details:- MIMIC semaphore indicator cutout-43mm
Bezel- 53mm round
Voltage- DC 24,48,110,220
Models-
MIMIC-sp-43-24-dc
MIMIC-sp-43-48-dc
MIMIC-sp-43-110-dc
MIMIC-sp-43-220-dc
Applications :- Circuit Breaker Panel MIMIC Diagram
Specifications :-
Rated Insulation Voltage (Ui) : AC, DC 250V.
Rated Operational Voltage (Ui) : DC 24V, 30V, 48V, 110V, 220V.
Voltage Fluctuation Range : ±15%
Rated Operational Current (Ie) : 11 mAmax
Insulation Resistance : 1000MΩ over Impulse Withstand
Voltage : ± 4500V,
3 Times For EachPole (1.2/50µs) Shock Resistance : 490m/s²
Durability : over 10000 Cycles
Degree Of Protection : IP52
Operating Temperature : -20 to 60° C
Storage Temperature : -30 to 75° C
Relative Humidity : 45 to 85 %
Altitude : Max 2000m
Compatiable Copper Conductor : AWG 20 to 14
Mounting Plate Thickness : 1 to 6mm
Confirming to Standard : IEC 60947-5-1, IEC 60947-1
Indication: vertical red , horizontal green
Connection: 1-red,2-green,3-common
Details:- MIMIC semaphore indicator cutout-43mm
Bezel- 53mm round
Voltage- DC 24,48,110,220
Models-
MIMIC-sp-43-24-dc
MIMIC-sp-43-48-dc
MIMIC-sp-43-110-dc
MIMIC-sp-43-220-dc
Applications :- Circuit Breaker Panel MIMIC Diagram
Specifications :-
Rated Insulation Voltage (Ui) : AC, DC 250V.
Rated Operational Voltage (Ui) : DC 24V, 30V, 48V, 110V, 220V.
Voltage Fluctuation Range : ±15%
Rated Operational Current (Ie) : 11 mAmax
Insulation Resistance : 1000MΩ over Impulse Withstand
Voltage : ± 4500V,
3 Times For EachPole (1.2/50µs) Shock Resistance : 490m/s²
Durability : over 10000 Cycles
Degree Of Protection : IP52
Operating Temperature : -20 to 60° C
Storage Temperature : -30 to 75° C
Relative Humidity : 45 to 85 %
Altitude : Max 2000m
Compatiable Copper Conductor : AWG 20 to 14
Mounting Plate Thickness : 1 to 6mm
Confirming to Standard : IEC 60947-5-1, IEC 60947-1
Indication: vertical red , horizontal green
Connection: 1-red,2-green,3-common
